Slab Bolster Dipped

  • Available heights – ¾”, 1”, 1.5”, 2”, 2.5”, 3” and 3.5”
  • 5 foot lengths
  • Legs are spaced 5” on center

Slab Bolster Upper • Plain

  • Available heights – ¾”, 1”, 1.5”, 2”, 2.5”, 3”, 3.5”, 4”, 4.5”, 5”, 5.5” and 6”
  • 5 foot lengths
  • Legs are spaced 5” on center

Beam Bolster Dipped

  • Available heights – 1”, 1.5” and 2”
  • 5 foot lengths
  • Legs are spaced 2.5” on center

Beam Bolster Upper-Plain

  • Available heights – 1”, 2” and 3”
  • 5 foot lengths
  • Legs are spaced 2.5” on center

Continuous High Chair Upper-Plain

  • Available heights – 1”, 1.5”, 2”, 2.5”, 3”, 3.5”, 4”, 4.5”, 5”, 5.5” and 6”
  • 5 foot lengths
  • Legs are spaced 8” on center

Individual High Chairs Dipped

  • Available heights – 2”, 2.5”, 3”, 3.5”, 4”, 4.5”, 5” and 6”

Steel Stake

  • 18 inches long, used as a grade stake
  • Max bar size #5
  • 4 different locations for placement of rebar-9”, 11”, 13” and 16 ½”
  • Recommended spacing 5 feet
  • Used in footings and other concrete applications
