Plastic Slab Bolster

  • Available heights – ¾” / 1” / 1.25” / 1.5” / 1.75” / 2” / 2.25” / 2.5” / 2.75” / 3”

  • 30” lengths

  • Slab Bolsters can be extended to longer lengths through its snapped locking system

  • The pointed tips allow minimum point of surface contact

  • Ideal for pouring precast, poured decks, tilt-up and other structures that require additional rebar reinforcement



Grade Chair with Base

  • Each chair comes with two height options

  • Available heights – 1.5”-2”/ 2"-2.5”/ 2.5"-3”/ 3.5”-4”/ 4.5"-5"/5.5"-6"

  • Max bar size #6

  • 800+ lbs. load bearing

  • Made from polymeric carbon abs material

  • Wide base allows for solid footing


F-Chair

  • Chair comes with two height options

  • Available heights – ¾”/ 1”

  • Max bar size #6

  • Wide base allows for solid footing


H-Chair-6 Leg

  • Available heights – 1”/ 1.5” / 2” / 2.5” / 3” / 3.5” / 4” / 4.5” / 5”/ 5.5” / 6”

  • Max bar size #11

  • 800 lbs. Load Bearing

  • Unbeatable design, strong and stable, due to that the same axel has two points for bar support

  • Suggested for multiple applications – concrete slabs, precast, tilt-up and concrete finish


H-Chair-4 Leg

  • Available heights – 1.5” / 2” / 2.5” / 3” / 3.5” / 4”

  • Max bar size #11

  • 600 lbs. load bearing

  • Unbeatable design, strong and stable, due to that the same axel has two points for bar support

  • Suggested for multiple applications – concrete slabs, precast, tilt-up and concrete finish



Heavy Duty Paving Chair

  • With or without base

  • Available heights -- 2"/ 2.5"/ 3"/ 3.5"/ 4"/ 4.5"/ 5"/ 5.5"

  • Max bar size #13

  • 800 lbs. load bearing

  • Extra heavy duty stable design

  • Suggested uses--slab or grade, some saddle application



Mesh Chair

  • With base -- available heights – 1” / 2” / 2.5” / 3” / 3.5”/ 4"/ 4.75"/ 5"/ 6"

  • Without base-- available heights -- 1"/ 2"/ 2.5"/ 3"

  • Mesh gauge: 3 – 10

  • 300 lbs. load bearing

  • Circular base will provide stability and support

  • Mesh chair is used for welded mesh and installed at four way crossing


Utility Chair

  • Available heights – 2.25” / 3.25”

  • Max bar size #4

  • Stable, light, economic and designed with 2 1/8” base

  • Used for slab work, precast and tilt-up


Foundation Footer Chairs

  • Available Sizes:

  • (RC-6-2) 6” width – 3” height - (RC-12-3) 12” width – 3” height

  • (RC-18-3) 18” width – 3” height

  • Max bar size #5

  • Eliminates tie wire

  • Dual clamping feature allows overlapping of rebar

  • RC-6-2 holds 2 pieces of rebar - RC-12-3 and RC-18-3 holds 3 pieces of rebar

  • Recommended spacing 4 feet


Spacer Wheels

  • Available sizes - ¾” / 1” / 1.25” / 1.5” / 1.75” / 2” / 2.5” / 3” cover

  • Has double fastener that works with rebar and welded mesh, maintaining them to the center of the spacer

  • Minimal surface contact

  • Spacer Wheel used for walls, columns, beams, cast-in-place and prefabrication


Drill Shaft Wheel

  • Available sizes – 2” / 3” cover

  • Max rebar size #6

  • Lateral spacer, impact resistant for heavy and large structures

  • Provides guide system for reinforcement cages within caissons, drilled shafts and other construction applications


Plastic Stake

  • 18 inches long, used as a grade stake

  • Max bar size #5

  • 4 different locations for placement of rebar - 9” / 11” / 13” / 16 ½”

  • Recommended spacing 5 feet

  • Used in footings and other concrete applications



Pyramid Chair

  • Available heights-- 1.25"/ 2"/ 2.5"/ 3"/ 3.5"/ 4.5"

  • Max bar size #4

  • 400 lbs. load bearing

  • Provides positive lock for quick and easy slab on grade work



Q-Decking Chair

  • Available heights-- .75"/ 1"/ 1.5"/ 2"

  • Max bar size #4

  • 400 lbs. load bearing

  • Provides positive lock for quick and easy slab on grade work


End Caps

  • Available sizes – CS075 #3, #6 bar and CS150 #8, #11 bar

  • Avoids possible knocks and scratches to workers in traffic zones

  • Used in horizontal applications
